Reasons and solutions for overheating of air compressor mainframe module



What should I do if the main module of the screw air compressor is overheated? What is causing it and what is a good solution? Let's analyze the causes and solutions for overheating of the screw air compressor mainframe module with everyone.


1. Environmental issues


During the operation of the machine, if there is no good ventilation and heat dissipation, it will have a great impact on the equipment. The main factors that affect the heat dissipation of the air compressor are: the space where the air compressor is placed is relatively small or other obstacles are too close, which is not conducive to timely heat dissipation; and there may be other heat sources near the air compressor. For this, it is recommended Install and use the air compressor in strict accordance with the operating instructions and safety environment requirements of the screw air compressor.


2. The radiator blockage problem


The air compressor has been used for a long time. If it is not maintained in time, more dust will inevitably fall on the machine. This will cause a layer of dust or sludge to adhere to the surface of the radiator, forming fouling, which will seriously affect the air compressor. heat radiation. Dirty oil filter may also cause a certain degree of overheating of the air compressor. The oil filter of the screw air compressor will be too dirty to prevent the oil from entering the air compressor at the normal flow rate. It is easy for the screw air compressor to quickly heat up due to insufficient cooling and lubricating oil, which will cause the machine to heat up. Of course, the cooling oil level is too low. It is suggested that the screw air compressor should be maintained and maintained regularly to avoid the occurrence of the above situation.


3. Due to the problem of low oil mark or poor oil quality


Screw air compressors should use the manufacturer’s original special air compressor oil. If other low-grade or inferior oils are used, the back viscosity and specific heat may not reach the standard and cause problems such as excessive temperature.


4. The oil filter is too dirty.


When the oil filter is too dirty, the oil cannot enter the compressor at the normal flow rate due to resistance, and the compression molding machine heats up rapidly due to insufficient lubrication. When the difference between the inlet and outlet oil exceeds 0.18MPa, the filter element needs to be replaced.


5. The cooling oil level is too low. When the cold machine is checked, if the oil level is lower than the lower end of the inspection tube, it should be replenished immediately.


Therefore, for the overheating of the screw air compressor mainframe module, we have to find out the reason in order to make the correct solution in time, conduct a reasonable analysis, eliminate hidden dangers in the bud, and protect unnecessary property losses and personnel safety.
