1. The unit occupies a small area. A certain installation operates as four compressors, three open and one standby, and the size of the workshop is 42mX16m. If the horizontal counter-balanced type reciprocating machine is used, three sets are required, two open and one standby, and the total occupied area is 38mX6m (the occupied area of a single unit is 16mX6m), and the labyrinth compressor is used, due to its structural characteristics (no piston rings) , support ring and packing ring), so there is no need to consider the risk of continuous operation caused by the replacement of wearing parts, so the working system is one open without preparation, and the area of a single labyrinth machine is only 14mX10m.
2. The number of wearing parts of the unit is greatly reduced. If the labyrinth compressor is used, its sealing principle is throttling seal, and there are no wearing parts such as piston rings, support rings and packing rings. However, the horizontal counter-balanced reciprocating machine has a large number of wearing parts, and the nitrogen medium has a brittle effect on the wearing parts (the material is filled with PTFE self-lubricating material), which greatly reduces the service life and increases the continuous flow of the unit. Operational risk also greatly increases the workload of follow-up inspection and maintenance, wastes a lot of human resources, and at the same time requires greater storage requirements for future spare parts and higher operating costs.
3. High efficiency. Due to the use of labyrinth compressor, there is no direct blocking friction between the cylinder and the piston seal, which can save a lot of energy loss, saving 40kW·h.
4. The cost of land use and the amount of on-site construction have dropped significantly. Due to the use of labyrinth compressors, the unit occupies a small space, the required workshop area is small, and the civil construction foundation is small, the on-site construction workload is greatly reduced, and the installation time can be greatly shortened.
5. The pipeline layout is simple and should not cause pipeline vibration. Due to the use of labyrinth compressors, the number of units is reduced, the pipeline arrangement is easier, there is no mutual influence of multi-unit work and process medium airflow pulsation during switching, and the possibility of pipeline vibration is lower, which is conducive to long-term stable and continuous operation of the unit .
