20Nm3/min compressed air flange precision filter FRJX-200*

A precision filter is a filtering device used to remove tiny particles of impurities from fluids (liquids or gases).

  • Working Pressure:6~16[ bar ]87~290[ psig ]
  • Free Air Delivery:10.6~2294[ cfm ]0.3~65[ m3/min ]
  • Working Power:7.5~250[ kw ]10~350[ hp ]
PRODUCT
GALLERY

DOWNLOAD DOCUMENT

ROCKY CATALOG 2025 VERSION Rocky RKY RKYII Portable compressor catalog Rocky High Pressure Breathing Air Compressor Catalog 2025 Rocky Medium High pressure air compressor catalog

Product Details

铝合金过滤器 (25).jpg

Product feature

1. High filtration accuracy: It can effectively remove tiny particles, and the filtration accuracy can reach 0.1 micron.

2. Stable filtration performance: Under certain pressure and flow, the filtration effect is stable.

3. A variety of filter media are available: Different filter media can be selected according to different filtration needs.

4. Easy to maintain and replace: The filter element is usually designed to be replaceable and easy to maintain.

5. Wide range of applications: It can be used for filtration of liquids and gases.



Technical Parameters

Filter modelFlow (m3/min)Interface CModel of filter
element
RJ-010*1.2 1/2"or 3/4" or 1"FJ-010*
RJ-020*2.3 1/2"or 3/4" or 1"FJ-020*
RJ-030*3.5 1" or 1-1/2"FJ-030*
RJ-050*5.7 1-1/2"FJ-050*
RJ-070*7.8 1-1/2"FJ-070*
RJ-110*11.6 2"FJ-110*
RJ-150*15.5 2"FJ-150*
RJX-200*20 2-1/2"FJX-200*
RJX-250*25 2-1/2"FJX-250*
RJX-300*30.8 3"FJX-300*
RJX-400*40.5 4"FJX-400*
FRJX-200*20 DN65FJX-200*
FRJX-250*25 DN65FJX-250*
FRJX-300*30.8 DN80FJX-300*
FRJX-400*40.5 DN100FJX-400*
