German Original GHH Screw Airend CF128G Screw Compressor Head

The CF128G is a single-stage oil-filled screw compressor for belt drive and direct drive systems. The free end can be used for general industrial applications.

  • Working Pressure:6~16[ bar ]87~232[ psig ]
  • Free Air Delivery:144~735.4[ cfm ]4.1~20.8[ m3/min ]
  • Working Power:19.4~198[ kw ]26~265.7[ hp ]
PRODUCT
GALLERY

DOWNLOAD DOCUMENT

ROCKY CATALOG 2025 VERSION Rocky RKY RKYII Portable compressor catalog Rocky High Pressure Breathing Air Compressor Catalog 2025 Rocky Medium High pressure air compressor catalog

Product Details

The CF128G  is a single-stage oil-filled screw compressor for belt drive and direct drive systems. The free end can be used for general industrial applications.


Technical Parameters

Model

Power

(kW)

Flow

 (m³/min)

Working pressure
( bar)		Weight
(kg)
CE55RW15,81.771322
CE55G272.641430
OS7044,64.611543
CF75D861,36.161557
CF75G73,36.941570
CF90G585,48.8715120
CF90LG388,611.210129
CF90D3101101589
CF90LG510512.610129
CF128G19820.815280
CF128LG22228.810330
CF180R38541.415725
OS11013914.6815150
OS16329532.6515430
CF180G238541.415780
CF246G56566.613.51600
