Silent Oil Free Screw Air Compressor 75KW 100HP Water Lubricated Air Compressor

Oil free water lubrication screw air compressor is a kind of compressor that provides clean, pollution-free, 100% oil free screw air compressor, its zero emission can protect the environment efficient

Working Pressure:8~12.5[ bar ]232~182[ psig ]
Free Air Delivery:342.4~459[ cfm ]9.7~13[ m³/min ]
Working Power:75[ kw ]100[ hp ]

PRODUCT
GALLERY

DOWNLOAD DOCUMENT

ROCKY CATALOG 2025 VERSION Rocky RKY RKYII Portable compressor catalog Rocky High Pressure Breathing Air Compressor Catalog 2025 Rocky Medium High pressure air compressor catalog

Silent Oil Free Screw Air Compressor 75KW 100HP Water Lubricated Air Compressor

Product Details

Product features

Optimal Water Lubricated Screw Unit

The oil-free water lubricated screw unit adopts PEEK ultra-high-strength ultra-wear-resistant molecular material and aerospace-grade all-stainless steel rotor. The system piping and housing are also made of stainless steel.

Class 0 Oil-free

Water is used for lubrication, cooling, sealing and noise reduction. 100% oil-free and pollution-free, the used water is environmentally friendly and can be drained directly.

Reliable Solenoid Valve

Danfoss and ODE solenoid valves are selected, high sensitivity & longer lifetime.

Less Consumables and Easy Operation

Air filter and water filter only. Lubricating water is automatically replenished and drained regularly.

Application industry

Oil-free Water Lubricated Screw Air Compressor is widely used in Food, Medicine, Electronics ,Chemicals, Aerospace fields, Semiconducto,Precision Spraying, Biological Engineering, Medical instruments other industries.

Technical Parameters

Model	Air Delivery (m3/min)			Power (kW)	Lubricating water amount (Liters)	Cooling water amount T/Hour	Cooling water inlet/outlet diameter	Noise dB(A)	Outlet diameter	Dimension (mm)	Weight (Kg)
Model	8 bar	10 Bar	12.5 bar	Power (kW)	Lubricating water amount (Liters)	Cooling water amount T/Hour	Cooling water inlet/outlet diameter	Noise dB(A)	Outlet diameter	LWH	Weight (Kg)
RW-08A/W	1.17	1.05	0.81	7.5	10	2.0	3/4"	58	3/4"	8008001200	470
RW-11A/W	1.65	1.42	1.10	11	26	2.5	1"	60	3/4"	11507551340	580
RW-15A/W	2.43	2.17	1.80	15	26	3.5	1"	63	3/4"	11507551340	650
RW-18A/W	3.13	2.82	2.05	18.5	30	4.0	1"	65	1"	14009001450	705
RW-22A/W	3.52	3.21	2.78	22	30	5.0	1"	65	1"	14009001450	745
RW-30A/W	5.12	4.43	3.63	30	40	7.0	1 1/2"	67	1 1/4"	155011501550(A) 150011501300(W)	1100
RW-37A/W	6.30	5.33	4.77	37	40	9.0	1 1/2"	67	1 1/4"	155011501550(A) 150011501300(W)	1150
RW-45A/W	7.40	6.30	5.56	45	90	10.0	1 1/2"	68	2"	198013001760(A) 180013001670(W)	1390
RW-55A/W	9.60	8.55	7.67	55	120	12.0	1 1/2"	70	2"	198013001760(A) 180013001670(W)	1470
RW-75A/W	13.00	11.50	9.70	75	120	18.0	1 1/2"	73	2"	210016001900(A) 220015001800(W)	2250(A) 1630(W)
RW-90A/W	14.80	13.90	12.60	90	180	20.0	1 1/2"	73	2 1/2"	240016002000(A) 220015001800(W)	2650(A) 2350(W)
RW-110A/W	19.85	16.66	15.56	110	180	24.0	2"	78	2 1/2"	300017002250(A) 220015001800(W)	3150(A) 2460(W)
RW-132A/W	23.10	19.97	16.90	132	240	30.0	2"	78	2 1/2"	300017002250(A) 220015001800(W)	3500(A) 2500(W)
RW-160W	28.11	25.45	22.52	160	240	35.0	3H	80	DN80	270028002050	3700
RW-185W	33.97	29.00	25.21	185	300	38.0	3"	80	DN80	270028002050	3750
RW-200W	36.75	32.78	29.24	200	300	42.0	4"	80	DN100	270028002050	3900
RW-220W	39.67	36.75	29.63	220	360	47.0	4"	80	DN100	270028002050	4200
RW-250W	43.50	39.30	34.00	250	360	58.0	4"	80	DN100	270028002050	4600
