7.5~15hp air compressor head TMC screw air end SCA7AL

5.5~11KW Screw Air End Italian TMC Air Compressor Air End SCA7LA. This original TMC air end comes with a long life warranty, ensuring stable running and providing enough flow rate. Made with cast iron

  • Working Pressure:6~10[ bar ]87~232[ psig ]
  • Free Air Delivery:10.6~38.8[ cfm ]0.3~1.1[ m3/min ]
  • Working Power:  5.5~11[ kw ]7.5~15[ hp ]
PRODUCT
GALLERY

DOWNLOAD DOCUMENT

Rocky catalog 2024 version Rocky RKY RKYII Portable compressor catalog Rocky High Pressure Breathing Air Compressor Catalog Rocky high precision line filter catalog

Product Details

5.5~11KW Screw Air End Italian TMC Air Compressor Air End SCA7LA. This original TMC air end comes with a long life warranty, ensuring stable running and providing enough flow rate. Made with cast iron, it is a reliable and customizable component for your screw air compressor.


Technical Parameters

ModelPower（kW）Pressure(bar)Diemension(mm)Weight(kg)
SCA7AL      5.5~113~13233*133.5*11510
SCA8DA5.5~113~15217*184.5*16418
SCA9DA7.5~153~15237*260*20740
SCA10DR  22~373~15228.5*260*20745
SCA13DR    37~453~15498*288*25574
SCA14DR    55~753~15503*312*280108
SCA14GR    75~903~15590*358*260140
SCA20DR    1103~15617*459*350263
SCA20GR   100~1323~15759*459*350320
SCA22DR    1323~15710*527*425393
