353cfm Stationary Electric Screw Compressor Diesel Air Compressor

Rocky diesel relocation machine can meet the requirements of overload use, and can withstand the worst on-site environment. At the same time, it can also reduce fuel consumption, thereby greatly reduc

  • Working Pressure:8[ bar ]116[ psig ]
  • Free Air Delivery:353[ cfm ]10[ m3/min ]
  • Working Power:78[ kw ]104[ hp ]
PRODUCT
GALLERY

DOWNLOAD DOCUMENT

Rocky catalog 2024 version Rocky RKY RKYII Portable compressor catalog Rocky High Pressure Breathing Air Compressor Catalog Rocky high precision line filter catalog

Product Details

Rocky diesel relocation machine can meet the requirements of overload use, and can withstand the worst on-site environment. At the same time, it can also reduce fuel consumption, thereby greatly reducing operating costs. With wheel design, it is easy to move and maintain, and is widely used in drilling, mining, road repair, engineering rescue and other industries.

固定式柴油机 (3).jpg

Technical Parameters

ModelRSCY185RSCY-250RSCY-360
Diesel engineXichaiXichaiXichai
Rated power41kw /37kw55kw78kw/74kw
Displacement5m³/min7m³/min10m³/min
Displacement pressure8 bar8 bar8 bar
Compression level BaosiBaosiBaosi
Air tank capacity80L80L70L
Screw compressor oil level25-30L35L35L
Engine model4DW91-56G2/4DW91-50GBG3U4DW93-75GG3U4DX22-96GG2/4DX23-100GG3U
Emission standardChina II/China IIIChina II/China IIIChina II/China III
Rated speed2300 rpm2200 rpm2200 rpm
Idle speed1350 rpm1300 rpm1300 rpm
Diesel engine lubricating oil7L7L7L
Coolant volume20L20L20L
Fuel tank capacity60L60L65L
Average fuel consumption10- 12L10- 12L10-12L
Dimensions2 Wheel mobile 2600* 1500* 1320mm
Fixed 1800* 1100*900mm		2Wheel mobile  2700* 1550* 1320mm
Fixed 1900* 1150*900mm		2Wheel mobile  2900* 1920* 1750
Fixed 2040* 1400* 1300
Weight2 Wheel mobile  1000kg
Fixed  865kg		2 Wheel mobile  1150kg
Fixed  1000kg		2 Wheel mobile 1300kg
Fixed 1150kg
