GD300-21 series air compressor dual frequency conversion all-in-one machine is a special dual frequency conversion all-in-one machine designed and developed for synchronous or asynchronous twin-screw
GD300-21 series air compressor dual frequency conversion all-in-one machine is a special dual frequency conversion all-in-one machine designed and developed
by INVT for synchronous or asynchronous twin-screw air compressors. It is used in conjunction with INVT's HMI touch screen to perfectly realize the drive and
management of twin-screw air compressors. GD300-21 air compressor all-in-one machine can provide air compressors with dual frequency conversion outputs for
the host and fan, provide +24V power to the touch screen, control the solenoid valve, and receive temperature and pressure signals. It completely replaces the
original air compressor dual frequency conversion electrical control cabinet in terms of function. However, compared with the previous electrical control cabinet,
the volume of the all-in-one machine is greatly reduced, and installation and debugging have become easier.
Power range:
Three-phase 220V (-15%) ~ 240V (+10%) 7.5~45KW
Three-phase 380V (-15%) ~ 440V (+10%) 15~90KW
Product feature
1. Dual frequency conversion drive and control in one
The main engine and oil temperature fan are dual frequency conversion drive and control in one, which makes the control more intelligent and the
air compressor more energy-saving and efficient.
2. Dual-stage dual-drive control
The integrated unique dual-drive constant pressure control algorithm makes the dual-stage dual-drive air compressor always run in the best operating state.
3. Integrated integrated design
The functions and configurations are highly integrated, which reduces the customer's electrical cabinet assembly time by 80%, greatly reducing the customer's
product material cost and manufacturing costs.
4. Stable and reliable
Design, testing and production are strictly carried out in accordance with IEC international standards to ensure the reliable operation of the product in various
harsh environments.
5. Smart Internet of Things cloud platform
The optional 4G Internet of Things data terminal can be connected to the air compressor dedicated Internet of Things cloud platform to realize real-time detection
of operating status, maintenance reminders, fault alarms and intelligent analysis, remote maintenance, intelligent management of equipment operating status,
equipment energy efficiency data analysis and other functions; in addition, it supports customized deployment of private cloud platforms, with diversified choices
and good data confidentiality.
