Stainless Steel Sterile PTFE Compressed Purity Filter Accessories RF-010

The sterilizing filter is mainly a microfiltration filter element with a large specific surface area and a filtration accuracy of 0.22um or more. It is mainly used to prevent impurities and harmful ba

  • Working Pressure:6~20[ bar ]87~290[ psig ]
  • Free Air Delivery:10.6~2294[ cfm ]0.3~65[ m3/min ]
  • Working Power:7.5~250[ kw ]10~350[ hp ]

Product Details

The sterilizing filter is mainly a microfiltration filter element with a large specific surface area and a filtration accuracy of 0.22um or more. It is mainly used to prevent impurities and harmful bacteria in the air, production lines, and sterile rooms from causing changes in water quality, products, and sterile room environments. , to meet the industrial needs of food, biochemical, beverage, beer, medicine, electronics and other industries.

不锈钢除菌过滤器 (2).jpg


Technical Parameters

Filter modelCapacity
M³/min

Connection

 sizes

Filter element
model
Filter element
qty (pcs)
RF-0101-3Quick Connect/ Thread 1"226*5
RF-0504-6Quick Connect/ Thread 1"226* 10
RF-0707-10Quick Connect /Thread 1.5"226*20
RF-10015-20DN65226*20
RF-20030-35DN80226*20
RF-30040-55DN100226*20
RF-40060-75DN125226*20
RF-50080-100DN125226*20
RF-600110-120DN150226*2011
RF-700130-140DN150226*2013
RF-800150-160DN200226*2015
